Lantronix LPS1-T, MPS100, LPS1-2 manual LPR on Windows 95/98, LPR on Unix Hosts

TCP/IP Configuration LPR Printing

10Test the printer by choosing Yes and clicking Finish.

4.2.2 LPR on Windows 95/98

To enable LPR printing on Windows 95/98, you must download and install the LPR for Windows 95/98 application from the Lantronix CD included with the product.

1From the Distribution CD, install Lantronix LPR.

2Follow the directions in the readme file to configure LPR on your PC.

4.2.3 LPR on UNIX Hosts

The Berkeley remote printing system is supported on many machines, and is simple to con- figure. This section describes how to configure LPR print queues on generic UNIX hosts such as SUN hosts. There are slight variations in LPR configuration for AIX, HP, and SCO hosts, as will be explained in the following sections.

1Install a print queue on your host by adding the MPS name and IP address to the /etc/hosts file:

Figure 4-6:Adding /etc/hosts Entry

xxx.xxx.xxx.xxx MPS_xxxxxx

2Add the host print queue to the /etc/printcap file. The punctuation shown in Figure 4-7 is required, and no extra spaces should be added.

Figure 4-7:Adding /etc/printcap Entry

mps_prtPrinter on LAB MPS:\ :rm=MPS_xxxxxx:\ :rp=MPS_xxxxxx_TEXT:\ :sd=/usr/spool/lpd/mps_prt:

4-7
