Primera Technology 510212 manual Applying Power

Page 23

Digital Label Press 3 User’s Manual

I. APPLYING POWER

1.Locate the power cord supplied with your press.

2.With the press's power switch turned off, place one end of the power cord into the power port on the rear panel of the press.

18

Section 3: Getting Started
