MultiVOIP 200 User Guide

Appendix B: Configuration Profiles

Quick Setup Factory Profiles

For quick setup, the MTA128ST-USB includes six Quick Setup Factory Profiles, each of which is configured for a specific type of port operation. You can load a Quick Setup Factory Profile into active memory by using the command &Fn, in which n is the number of the profile you wish to load. If you wish, you can then customize the profile and store it, using the &W command, so that it loads automatically when the MTA128ST-USB is turned on or reset. These profiles are stored in permanent memory and are not user-configurable as such.

&F0	Profile 0— Modem-like operation (default)
&F1	Profile 1— V.110 async operation
&F2	Profile 2— V.120 async operation
&F3	Profile 3—	X.75 async operation
&F4	Profile 4—	ML-PPP async operation

Note: The &F1 command will return an error when used with build MT128ST-USB-RC.

Quick Setup Example

The following procedure assumes that you want to load, modify, and store Quick Setup Factory Profile 2 as your default configuration.

1.Select the profile closest to the requirements of your application, in this case— Quick Setup Factory Profile 2.

2.In terminal mode, type AT&F2 and press ENTER. Quick Setup Profile 2 loads into the MTA128ST- USB’s active memory.

3.Enter any additional AT commands that you need to customize the selected profile to your application (see Chapter 4, AT Commands, S-Registers, and Result Codes).

4.Type AT&W0 and press ENTER to save your customized port configuration.

5.Your customized profile now loads automatically whenever the MTA128ST-USB is turned on or reset.

Profile 0 (&F0) — Modem-Like Asynchronous Operation

AT COMMAND	DESCRIPTION
&C1	DCD functions normally
$D0	Disable persistent DTR dialing
&D1	Hang up when DTR drops
E1	Enable command mode echo
&E4	Enable hardware flow control
&E6	Discard XON/XOFF characters
&E13	Enable pacing
#X0	Disable Sending Multiple Xoff Characters
&J0	Disable Automatic Channel Bundling
%E1	Enable +++ escape method
%E4	No OK response to +++ or <break> escape
&R1	CTS always high

90

Image 90
