Panasonic AJ- HD3700B manual Connector signals

Page 44

Connector signals

∑ VIDEO IN

HD SDI (DIGITAL)	BNCk2, active through
SD SDI IN (DIGITAL)	BNCk2, active through
SD SDI SPARE	BNCk1
HD REF IN	BNCk2, loop-through with 75 ≠ termination switch
SD REF IN	BNCk2, loop-through with 75 ≠ termination switch

∑ VIDEO OUT

HD SDI OUT (DIGITAL)	BNCk3
HD SDI MONITOR OUT	BNCk1
(DIGITAL) (SUPER)
SD SDI OUT (DIGITAL)	BNCk2
SD SDI MONITOR	BNCk1
(DIGITAL) (SUPER)

VIDEO OUT (ANALOG)	BNCk3
HD REF OUT	BNCk1
SD REF OUT	BNCk1
WFM	BNCk1, Waveform output, 75 ≠.

∑ TIME CODE

TIME CODE IN	XLRk1
TIME CODE OUT	XLRk1

∑ AUDIO IN

AUDIO IN (DIGITAL)	BNCk4, CH1/2, CH3/4, CH5/CH6, CH7/CH8,
	AES/EBU format
AUDIO IN (ANALOG)	XLRk4, CH1, CH2, CH3, CH4
CUE IN	XLRk1

∑ AUDIO OUT

AUDIO OUT (DIGITAL)	BNCk4, CH1/2, CH3/4, CH5/CH6, CH7/CH8,
	AES/EBU format
AUDIO OUT (ANALOG)	XLRk4, CH1, CH2, CH3, CH4
CUE OUT	XLRk1
MONITOR	XLRk2
HEADPHONES (FRONT)	1⁄4q phone

– 44 –

Image 44
