VIVOTEK - A Leading Provider of Multimedia Communication Solutions

“HEX” digits consist of the numbers 0~9 and the letters A-F.

“ASCII” is a code for representing English letters as numbers from 0-127 except “, <, > and space characters that are reserved.

“Network Key” Entering a key in either hexadecimal or ASCII format. When selecting different key length, acceptable input length is listed as following:

64 bits key length: 10 Hex digits or 5 characters.

128 bites key length: 26 Hex digits or 13 characters.

Note: When 22(“), 3C(<) or 3E(>) are input in network key, the key format can’t be changed to ASCII format.

“Algorithm” Choosing one of the following algorithm for WPA-PSK modes

“TKIP” “AES”

“Pre-shared Key” Entering a key in ASCII format. The length of the key is 8 ~ 63

After wireless configurations are completed, click Save and the camera will Some invalid settings may cause the system failing to respond. Change the

reboot. Wait for the live image is reloaded to your browser. For VIVOTEK 7K configuration only if necessary and consult with your network supervisor or experienced series cameras, you have to unplug the power cable and Ethernet cable from the users for correct settings. Once the system has lost contact,Ther fer to Appendix A for reset

camera; then re-plug the power cable to the camera. camera will switch to

wirelessand re toremodeprocedures. .

!Some invalid settings may cause the system failing to respond. Change the configuration only if necessary and consult with your network supervisor or experienced users for correct settings. Once the system has lost contact, refer to Appendix A for reset and restore procedures.

- 37 -

www.vivotek.com

37 - User's Manual
