6 Operation

IL•1F CANopen DS301

6.4.1Operating mode Profile Position: absolute positioning

To start an absolute positioning movement, the following settings must be made in the R_PDO4:

￿Enter the reference speed in "Ref16" and the target position in "Ref32".

￿Enter operating mode 03h (Profile Position operating mode, abso- lute positioning) in the field modeCtrl.

￿Change modeCtrl, bit 7, so the data is taken over by the product.

Example Absolute positioniing to position 100,000 (000186A0h) at a reference speed of 1000 min-1(03E8h)





Master <---

> Slave







Triggering positioning

R_PDO4

--->

drivectrl

modeCtrl

Ref16

Ref32







02h

83h

03E8h

000186A0h

Positioning runningx_err = 0,

T_PDO4

<---

driveStat

modeStat



p_act

x_end = 0





0006h

83h



XXXXXXXXh

Positioning completex_err = 0,

T_PDO4

<---

driveStat

modeStat



p_act

x_end = 1, x_info = 1





6006h

83h



000186A0h

Table 6.4 Operating mode Profile Position, absolute positioning at constant ref- erence speed

Note: The data frame "positioning running" can be sent several times; the current actual position is contained in the field p_act.

Example As the above example, but the reference speed is changed to 2000 min-

1(07D0h) during the movement.





Master <---

> Slave







Triggering positioning

R_PDO4

--->

drivectrl

modeCtrl

Ref16

Ref32







02h

83h

03E8h

000186A0h

Positioning runningx_err = 0,

T_PDO4

<---

driveStat

modeStat



p_act

x_end = 0





0006h

83h



XXXXXXXXh

Change reference speed

R_PDO4

--->

drivectrl

modeCtrl

Ref16

Ref32







02h

03h

07D0h

000186A0h

Positioning runningx_err = 0,

T_PDO4

<---

driveStat

modeStat



p_act

x_end = 0





0006h

03h



XXXXXXXXh

Positioning complete x_err=0,

T_PDO4

<---

driveStat

modeStat



p_act

x_end = 1, x_info = 1





6006h

03h



000186A0h

Table 6.5 Operating mode Profile Position, absolute positioning with change of reference speed

Note: The data frame "positioning running" can be sent several times. The current actual position is contained in the field p_act. When the ref- erence speed is changed, the same target position is sent because it does not change in this example.
