Panasonic KX-TG365SK, KX-TG7845, KX-TG7873 Setting up, Connections, Base unit KX-TG7841 series

Page 10

Getting Started

Setting up

Connections

RIf you do not connect the telephone line cord and use only cellular lines, set the cellular line only mode to use this unit more conveniently (page 19).

n Base unit (KX-TG7841 series: page 3)

RUse only the supplied Panasonic AC adaptor PNLV226.

Press plug firmly.

Hook	“Click”
	“Click”
“Click”
To single-line
telephone jack
(RJ11C)	DSL/ADSL filter*

To power outlet

n Base unit (KX-TG7871 series: page 3)

RUse only the supplied Panasonic AC adaptor PNLV234.

RThe hook of the base unit is not designed to hold the AC adaptor cord for the desk stand or wall mounting use (page 67).

“Click”“Click”

To single-line

telephone jack “Click” (RJ11C)

DSL/ADSL filter*

To power outlet

*DSL/ADSL filter (not supplied) is required if you have DSL/ADSL service.

nCharger

Correct

Incorrect

To power outlet

*DSL/ADSL filter (not supplied) is required if you have DSL/ADSL service.

10For assistance, please visit http://www.panasonic.com/help
