JVC DR-MV5S Recording Medium And Format, Unplayable Discs, File Structure Of Discs, Region Number

Page 9





DISC INFORMATION EN 9

DVD-AUDIO discs compatible with DVD video players can be played.



Recording Medium And Format









Super Audio CDs (SACD) compatible with conventional CD players









DVD-RAM

can be played.



It is possible to play back finalized +R/+RW (Video mode only) discs.



Recording and erasing can be performed as many times as possible

“DVD” lights on the front display panel when a +R/+RW disc is



on a disc.

loaded.



Editing can be performed after recording, such as deleting unwanted

However, the use of +R double layer disc on this unit may not be



parts.

recommended.



While recording, it is possible not only to start playback of a program

Unplayable Discs



currently being recorded, but also to watch another program



previously recorded.





DVD-RW (VR mode)

The following types of discs cannot be played using this unit.



Recording and erasing can be performed as many times as possible

Do not attempt to play back any kind of disc that is damaged





on a disc.

(cracked, warped, or repaired with adhesive tape) or discs in





Editing can be performed after recording, such as deleting unwanted

unusual shapes (heart-shaped, octagonal, or other forms). If such





parts.

discs are accidentally played back, it may cause noise that can





DVD-RW (Video mode)

lead to speaker damage.





Can be played back on other DVD players after finalizing.

CD-ROM discs (including PHOTO-CD and CD-G)





New recording can be performed by erasing all the data on a disc

Discs recorded in Packet Write (UDF) format





once played back.

1.3-GB double density CDs (DDCD)









High density CDs (HDCD)



DVD-R

The following discs also cannot be played back.



Can be played back on other DVD players after finalizing.

Discs of a region number other than “1”



Suitable when keeping a recorded disc for a long time.







DVD-RAM (2.6 GB/5.2 GB)



File Structure Of Discs

DVD-RAM (TYPE1)













DVD VIDEO

Caution for DualDisc playback





Typically, DVD VIDEO discs are made up of larger units called

The Non-DVD side of a “DualDisc” does not comply with the





“titles”. Each title has a number (title number) that can be used to

“Compact Disc Digital Audio” standard. Therefore, the use of





select desired titles. Titles are further divided into units called

Non-DVD side of a DualDisc on this product may not be





“chapters”. Each chapter has a number (chapter number) that can

recommended.





also be used to select desired chapters. Note that some discs are





Region Number



not divided into titles and chapters.



When you record a program on a DVD-RAM/RW (VR mode)





The world is divided into 6 regions for DVD VIDEO discs.



disc

DVD VIDEO discs are assigned a region number to indicate which



A single recording session results in a single title (a single

region they may be played back in. A disc cannot be played back



chapter). However, chapter marks are automatically inserted when

on this unit unless the region number of the disc matches that of



recording is paused, or audio changes from monaural to stereo

the unit. The region number for this unit is “1”. Only discs whose



due to commercial breaks, etc. It is also possible to insert chapter

region number includes “1” or “ALL” can be played back such as



marks at desired locations during playback. ( pg. 47)

shown below.



When you record a program on a DVD-R/RW (Video mode)

Examples of DVD VIDEO labels which can be played back



disc

using this unit.



A single recording session results in a single title (a single





chapter). However, chapter marks are automatically inserted when





recording is paused, or audio changes due to commercial breaks,





etc. It is also possible to insert chapter marks at desired locations





during either recording or playback. Once the disc has been





finalized, these chapter marks are deleted and new chapter marks

Marks of discs in this instruction manual



are assigned automatically approximately every 5 minutes.







Allows operation with a DVD-RAM disc.

Allows operation with a DVD-R disc.

Allows operation with a DVD-RW disc.

Allows operation with a DVD VIDEO disc.

Allows operation with a Video CD/Super Video CD (SVCD) disc.

Allows operation with an Audio CD disc.

Allows operation with a disc including MP3 files.

Allows operation with a disc including JPEG files.

DVD-RAM, DVD-RW, DVD-R or DVD VIDEO disc









Title 1



















Title 2







Chapter 1



Chapter 2





Chapter 3







Chapter 1





Chapter 2





Chapter 3















































































































In Video mode, even before finalizing, it is impossible to perform editing operations other than changing the disc name and/or title names and deleting programs and/or titles.

After finalizing, it is impossible to perform editing operations.
