JVC DR-MV5S manual Advanced Playback DVD, High-Speed Search, DVD TOP Menu Enter

Page 45

ADVANCED PLAYBACK EN 45

Advanced Playback (DVD)

Turn on the unit.

Turn on the TV and select the AV mode.

Slide the TV/DVD switch to DVD.

Press DVD so that the DVD lamp lights up on the unit.

DVD

0 – 9

TOP MENU

ENTER

rtwe

MENU

Locating The Start Point Of The Item Or Skip The Item

Press 2 or 6 during playback.

Pressing 6 locates the start point of the item or skips the item in the forward direction, then resumes playback.

Pressing 2 locates the start point of the item or skips the item in the reverse direction, then resumes playback.

When a DVD-RAM/RW/R disc is played

Current program



News

Previous

Drama

Next

Movie





program

program





























Reverse







Forward









: marked points ( pg. 47)

Example:

To locate the beginning of the next item, press 6 once. To locate the beginning of the current item, press 2 once. To locate the beginning of the previous item, press 2 three times.

When a DVD VIDEO, Audio CD or Video CD disc is played

Playback point

Locating A Desired Scene Using The DVD Menu

DVD VIDEO discs may have top menu and disc menu.

Top menu

DVD discs generally have their own menus which show the disc contents. These menus contain various items such as titles of a movie, names of songs, or artist information. You can locate a desired scene by using the top menu displayed on the TV screen. Press TOP MENU to access the top menu.

Disc menu

Disc menus include playback data (angle menu, subtitle menu, etc.) specific to each title.

Press MENU to access the disc menu.

1 Press TOP MENU or MENU to access the DVD menu.

2 Press rt w e to select a desired title, then press ENTER. Playback starts.

It may be possible to select the desired item using the number buttons depending on the menu

display.Example:

NOTE:

When “X” appears on the TV screen

in step 1, the disc does not have a top menu or disc menu.



Scene 2



Scene 3



Scene 4





(Chapter 2)



(Chapter 3)



(Chapter 4)





or



or



or





Track 2



Track 3



Track 4

















Reverse





Forward



Example:

To locate the beginning of the next item, press 6 once. To locate the beginning of the current item, press 2 once.

High-Speed Search

During playback, press 5for forward high-speed search, or 3 for reverse high-speed search.

Each press of the button increases the search speed for each direction.

To resume normal playback, press 4.

For Audio CD

You can perform 4 levels of speed search with 5 and 3. (Audio is active also during high-speed search.) You cannot perform slow motion for each direction.
