MAINTENANCE

PRECAUTIONS AND SYSTEM MAINTENANCE

•Place the set on a hard, flat surface so that the system does not tilt.

•Do not expose the set, batteries, CDs or cassettes to humidity, rain, sand or excessive heat caused by heating equipment or direct sunlight.

•Do not cover the set. Adequate ventilation with a minimum gap of 15 cm between the ventilation holes and surrounding surfaces is necessary to prevent heat build-up.

•The mechanical parts of the set contain self-lubricating bearings and must not be oiled or lubricated.

•To clean the set, use a soft, slightly dampened chamois leather. Do not use any cleaning agents containing alcohol, ammonia, benzene or abrasives as these may harm the housing.

Tape deck maintenance

To ensure quality recording and playback of the tape deck, clean parts A,B and C shown in the diagram below, after approx. 50 hours of operation, or on average once a month. Use a cotton bud slightly moistened with alcohol or a special head cleaning fluid to clean the tape deck.

1.Open the cassette holder by pressing STOP/EJECT 9 /.

2.Press PLAY 2 and clean the rubber pressure rollers C.

3.Press PAUSE ; and clean the magnetic heads A and also the capstan B.

4.After cleaning, press STOP/EJECT 9 /.

CD player and CD handling

•The lens of the CD player should never be touched!

•Sudden changes in the surrounding temperature can cause condensation to form and the lens of your CD player to cloud over. Playing a CD is then not possible. Do not attempt to clean the lens but leave the set in a warm environment until the moisture evaporates.

•Use only Digital Audio CDs.

•Always shut the CD door to keep the CD compartment dust- free. To clean, dust the compartment with a soft dry cloth

•To take a CD out of its box, press the center spindle while lifting the CD. Always pick up the CD by the edge and replace the CD back in its box after use to avoid scratching and dust.

•To clean the CD, wipe in a straight line from the center towards the edge using a soft, lint-free cloth. Do not use cleaning agents as they may damage the disc.

•Never write on a CD or attach any stickers to it.

A A B C

X

English

17
