F-20	TROUBLESHOOTING AND REPAIR	F-20
	STATIC SCR RECTIFIER ASSEMBLY TEST (continued)

FIGURE F.3 — REMOVE PLUGS J6 AND J5 TO PERFORM STATIC RECTIFIER ASSEMBLY TEST.

J6

J5

J3

J8

J1

J4

J2

Return to Section TOC

Return to Section TOC

Return to Master TOC

Return to Master TOC

TEST PROCEDURE

1.Disconnect main AC input power to the machine.

2.Remove the case top and side panels with a 3/8 in. nutdriver.

3.Remove the tool tray with a 5/16 in. nut- driver.

4.Verify that the capacitors have completely discharged with a volt- ohmmeter.

5.Disconnect plugs J6 and J5 from the control board . This electrically isolates the SCR bridge assembly. See Figure F.3.
