F-17	TROUBLESHOOTING AND REPAIR	F-17
	RECTIFIER DIODE BRIDGE TESTING (continued)

Return to Section

Return to Section TOC

Return to Section TOC

Return to Section TOC

Return to Master

Return to Master TOC

Return to Master TOC

Return to Master TOC

6.Turn the POWER MIG 255C ON/OFF POWER SWITCH to ON.

7.Carefully make the following voltage tests:

a.Turn the machine OFF between each test.

b.Carefully connect the meter plugs to the exposed lead connections.

c.Turn the machine ON to conduct the voltage test at J5 connector Control board

FROM	TO	EXPECTED
LEAD	LEAD	VOLTAGE

208	206	28 VAC
209	206	28 VAC

8.If any of the AC voltages tested are incorrect or missing, check the leads and connections. See the wiring dia- gram.

9. Make the following voltage test:

a. Turn the machine OFF between each test.

b. Carefully connect the meter probes to the exposed lead connections.

c. Turn the machine ON to conduct the voltage test.

FROM	TO	EXPECTED
LEAD	LEAD	VOLTAGE

354	206	36 VDC

10. If the DC voltage tested is incorrect or missing, and the AC voltages are cor- rect, the rectifier diode bridge may be faulty.

POWER MIG 255C
