F-37

TROUBLESHOOTING AND REPAIR

F-37

COMPONENT REPLACEMENT PROCEDURES

CONTROL PC BOARD REMOVAL AND REPLACEMENT

WARNING

Service and repair should only be performed by Lincoln Electric factory trained personnel. Unauthorized repairs performed on this equipment may result in dan- ger to the technician or machine operator and will invalidate your factory war- ranty. For your safety and to avoid electrical shock, please observe all safety notes and precautions detailed throughout this manual.

If for any reason you do not understand the test procedures or are unable to per- form the test/repairs safely, contact the Lincoln Electric service department for technical troubleshooting assistance before you proceed. Call 1-888-935-3877.

-------------------------------------------------------------------------------------------------------------------

CAUTION

Printed Circuit Boards can be damaged by static electricity. Follow static handling guidelines detailed in “PC Board Troubleshooting Procedures” at the beginning of this chapter.

------------------------------------------------------------------------------------------------------------------

DESCRIPTION

This procedure will aid the technician in the removal and replacement of the control

PC board.

MATERIALS NEEDED

5/16 in. Nutdriver

Static electricity grounding strap

POWER MIG 255C
