Black & Decker LGC120 instruction manual Fonctionnement FIG. G,H, Rangement

Page 22



FONCTIONNEMENT (FIG. G,H)





AVERTISSEMENT : sʼassurer que toutes les personnes et

animaux sont éloignés dʼau moins 6 m (20 pi).



Tenir lʼoutil comme indiqué à la

G





figure G.





Relever lʼappareil du sol.







Glisser le bouton de verrouillage







(15) (fig. H).







Appuyer sur la détente (16).









Pour le premier crochetage de la









saison, un déplacement lent est









recommandé car la terre est bien









tassée. Les prochains









crochetages seront plus rapides.









Ne pas essayer dʼameublir le sol









mouillé pour des raisons de









sécurité (électrique) et pour









prévenir le bourrage des dents.









En cas de travaux sous des









conditions qui provoquent le









bourrage des dents, relâcher la









détente, attendre lʼarrêt complet









des dents! RETIRER LE BLOC-









PILES! Utiliser un bâton ou un

H







tournevis pour retirer la matière







prise dans les dents. Le



15

16



fonctionnement continu de lʼoutil





avec les dents bourrées





surchargera gravement le moteur.







REMARQUE : Lʼappareil est doté









dʼun mécanisme intégré









dʼembrayage utilisé pour prévenir









des dommages permanents à









lʼappareil lors dʼobstruction des









dents ou en présence de









conditions de travail exigeantes.







Si lʼembrayage est enclenché, lʼappareil émettra un cliquetis bruyant. Ce cliquetis continuera jusquʼà ce que lʼobstruction soit dégagée ou que la condition de travail se normalise. Retirer le bloc-piles avant dʼessayer de dégager les dents de lʼappareil. Lʼutilisateur ne peut pas ajuster le mécanisme dʼembrayage.

MISE EN GARDE : ne pas essayer de dégager les dents en laissant tomber lʼoutil ou en le frappant au sol. De telles pratiques risquent dʼendommager lʼappareil.

RANGEMENT

Enlever et nettoyer toute trace de débris de lʼextérieur du cultivateur et à lʼintérieur du flasque avant le rangement. Voir la section ENTRETIEN.

MISE EN GARDE : NE PAS SUSPENDRE LʼAPPAREILPAR LA DÉTENTE.

Remarque : ne pas ranger lʼoutil sur des engrais ou des produits chimiques ou près de ceux-ci. Un rangement de cette sorte risque de provoquer une corrosion rapide.

PREVENTION DE LA CORROSION AVERTISSEMENT : porter des gants et une protection

oculaire adéquats lors du nettoyage de lʼoutil.

Les engrais et autres produits chimiques de jardin renferment des agents qui accélèrent gravement la corrosion du métal. Après utilisation de lʼoutil dans des endroits où des engrais ou des produits chimiques ont été utilisés, lʼoutil doit être ensuite immédiatement nettoyé.

Essuyer toutes les pièces exposées avec un chiffon humide. Lubrifier uniquement les pièces métalliques avec de lʼhuile à base de pétrole léger.

Lors du nettoyage, NE PAS immerger lʼoutil dans lʼeau ou lʼarroser au boyau.

22
