Main Unit Disassembly Process

IMPORTANT: Cable paths and positioning may not represent the actual model. During the removal and replacement of components, ensure all available cable channels and clips are used and that the cables are replaced in the same position.

NOTE: The product previews seen in the disassembly procedures may not represent the final product color or configuration.

Main Unit Disassembly Flowchart

Remove External Modules before proceeding

Remove

Keyboard

Remove

Hinge Cover

Remove

Upper Cover

Remove

Card Reader

Board

Remove

CRT Board

Remove

LAN Board

Remove

Mainboard

Remove

Bluetooth Module

Remove

LED Board

Remove

Button Board

Remove

LCD Module

Remove

Thermal Module

Remove

RTC Battery

Remove

Speaker Modue

Remove

CPU

Screw List



Step

Screw

Quantity

Part No.

















Upper Cover

M2*6

7

86.S6507.001



















M2*4

12

86.W0107.003

















Hinge Cover

M2*10

2



















Button Board

M2*3

2

86.S0207.001

















I/O Board

M2*3

2

86.S0207.001

















VGA Board

M2*3

1

86.S0207.001

















LCD Module

M2*3

2

86.S0207.001

















LED Board

M2*3

2

86.S0207.001

















Speaker Module

M2*3

3

86.S0207.001

















Mainboard

M2*3

3

86.S0207.001

















Thermal Module

M2*3

5

86.S0207.001



























Chapter 3

49

Page 59
Image 59
