Cisco TelePresence System 3200

OL-14521-01

Chapter 2 Building the Display Assembly

Parts List

Step 8 Attach the upper and lower Support crossbars to the center Display structure .

Figure 2-8 Upper and Lower Support crossbars

Tip Use the screw holes nearest the ends of the Support crossbars.

201108
