Dell P713w Paper jam in the duplex unit

1Press to turn o ff the printer.

2Check the paper tray or lift the scanner unit to check for jammed paper.

3Firmly grasp the paper, and then gently pull it out.

Note: Be careful not to tear the paper while removing it.

4Press to turn the printer back on.

Paper jam in the duplex unit

Note: The parts inside the printer are sensitive. Avoid unnecessarily touching these parts while clearing jams.

1Push down the duplex latches and pull out the duplex unit.

CAUTION—POTENTIAL I NJURY: The area behind the duplex cover has protruding ribs as part of the paper

path. To avoid injury, use caution w hen accessing this area for clearing a paper jam.
