Removal and Replacement Procedures
5.12 LED Board
LED Board Spare Part Number Information
LED board (includes LED board cable) | |
|
|
1.Prepare the computer for disassembly (Section 5.3) and then remove the following components:
a.Memory/Mini PCI module compartment cover (Section 5.6)
b.Switch cover (Section 5.10)
c.Keyboard assembly frame (Section 5.11)
2.Turn the keyboard assembly frame upside down with the LED board toward you.
