Removal and Replacement Procedures

5.13 Keyboard

Keyboard Spare Part Number Information

For use in:







France

403809-051

Spain

403809-071

French Canada

403809-121

Sweden and Finland

403809-101

Germany

403809-041

United Kingdom

403809-031

Italy

403809-061

United States

403809-001

Norway

403809-091













1.Prepare the computer for disassembly (Section 5.3) and then remove the following components:

a.Memory/Mini PCI module compartment cover (Section 5.6)

b.Switch cover (Section 5.10)

c.Keyboard assembly frame (Section 5.11)

2.Turn the keyboard assembly frame upside down with the LED board toward you.
