Removal and Replacement Procedures

5.24 PC Card Assembly

PC Card Assembly Spare Part Number Information

PC Card assembly

403835-001





1.Prepare the computer for disassembly (Section 5.3), and then remove the following components:

a.Hard drive (Section 5.4)

b.Memory/Mini PCI module compartment cover (Section 5.6)

c.Optical drive (Section 5.9)

d.Switch cover (Section 5.10)

e.Keyboard assembly frame (Section 5.11)

f.Display assembly (Section 5.14)

g.Top cover (Section 5.15)

h.System board (Section 5.16)
