BIOS Setup UtilitySY-7VCA

3-2.2 Hard Disks Type & Mode

Choose the type and mode for the hard disks that you have already installed.

Primary	Setting	Description	Note
(Secondary)
Master & Slave
IDE HDD Auto-
	Press	To auto-detect the HDD’s size,
Detection	Enter	head …on this channel
IDE Primary
	Auto	BIOS detects hard disk type	Default
Slave		automatically.
(User Type)	User	User defines the type of hard disk.
	None
Access Mode
	Auto	BIOS detects hard disk mode	Default
		automatically.
	Normal	Normal IDE hard disk	<528MB
	LBA	Enhanced IDE hard disk	>528MB
	Large	Large IDE hard disk (for certain
		hard disk)

Note: If you have any questions on your hard disk type or mode, ask

your hard disk provider or previous user for details.

3-2.3 Floppy Drives

Floppy Drives	Setting	Description	Note
Drives A & B
	360KB, 5.25 in.
	1.2MB, 5.25 in.
	720KB, 3.5 in.
	1.44MB, 3.5 in.		Default
	2.88MB, 3.5 in.
	None	Not installed
Floppy 3-Mode	Disabled		Default
Support	Drive A	Supports 3-mode	Special disk drive
	Drive B	floppy diskette:	commonly used in
	Both	740KB/1.2MB/	Japan
		1.44MB on selected
		disk drive.

62
