SOYO SY-7VCA user manual Security Option, Other Control Options

BIOS Setup Utility SY-7VCA

3-3.8 Security Option

Use this feature to prevent unauthorized system boot-up or use of BIOS

Setup. The following table describes the security settings.

	Setting	Description
Security Option	System	Each time the system is booted, the
		password prompt appears.
	Setup	If a password is set, the password prompt
		only appears when you attempt to enter the
		BIOS Setup program.

3-3.9 Other Control Options

Other Control	Setting	Description	Note
Options
OS Select for
	OS2	When using an OS2 operating
DRAM>64MB		system.
	Non-OS2	When using another,	Default
		non-OS2 operating system.

Report No FDD For WIN 95

Yes	Windows will release IRQ line 6	Default
	(normally used by the Floppy
	Disk Drive) after you disable
	your on-board FDD and set this
	field to [Yes].
No	Windows will reserve INT 6 for
	your FDD, whether it is disabled
	or not.

Video BIOS Shadow

Disabled

Enabled Default

The BIOS is shadowed in a 16K segment if it is enabled and if it has BIOS present.

These 16 segments can be shadowed from ROM to RAM. BIOS shadow copies BIOS code from slower ROM to faster RAM. BIOS can then execute from RAM.

67
