BIOS Setup Utility |
|
3-7.2 MULTI I/O ADDRESSES
Default settings for
Port | I/O Address | IRQ | Status |
|
|
|
|
LPT1 | 378H | 7 | ECP/EPP |
|
|
|
|
COM1 | 3F8H | 4 |
|
|
|
|
|
COM2 | 2F8H | 3 |
|
|
|
|
|
Warning: If a default I/O address conflicts with other I/O cards such as sound card, you must change one of the I/O addresses to remedy to this address conflict. (I/O addresses can be adjusted from the BIOS Setup Utility)
3-8 PC HEALTH STATUS
This option sets the Motherboard's PC Health Status.
CMOS Setup Utility – Copyright ( C )
PC Health Status
Current CPU Temp. |
| 25 º C / 77 º F |
| Item Help |
|
Current System Temp. |
| 40 º C / 104 º F |
|
| |
|
|
|
| ||
Current CPUFAN Speed |
| 5192 RPM |
| Menu Level 4 |
|
Current CHAFAN Speed |
| 0 RPM |
|
| |
|
|
|
| ||
Vcore |
| 2.02 V |
|
|
|
2.5V |
| 2.50 V |
|
|
|
3.3V |
| 3.31 V |
|
|
|
5V |
| 4.97 V |
|
|
|
12V |
| 11.70 V |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
áâàß:Move Enter:Select | ESC:Exit F1:General Help |
| |||
F5:Previous Values |
| F7: Optimized Defaults |
| ||
|
| ||||
|
|
|
|
|
|
Note: Starred (*) items will disappear when the [Resources
Controlled By] option is set to [Auto].
85
