Technicolor - Thomson TG784 Firewall, Changing the security level, Creating a new security level

7 Internet Security

7.1Firewall

Changing the security level

Proceed as follows:

1Browse to the Thomson Gateway Web Interface.

2On the Toolbox menu, click Firewall.

3The Firewall page appears. In the upper-right corner, click Configure.

4A list with security settings with a brief description is displayed.

5Select the security level of your choice and click Apply.

Creating a new security level

If you do not find a security level up to your need, you are able to create a new security level.

This feature is intended for advanced users only.

Proceed as follows:

1In the Toolbox menu, click Firewall.

2In the upper right corner, click Configure.

3In the Pick a task list, click Create a new Security Level.

4In the Name box, type a name for the new security level.

5In the Clone from existing Security Levels list, click the security level you want to start from.

6Click Apply.

7You can now make the necessary changes to the security level.

64 E-DOC-CTC-20080421-0010 v1.0
