Embedded DVR User Guide

PTZ

To enter PTZ mode:

•Right-click the Live screen and select PTZ on the pop-up menu, or

•Click the PTZ icon on the Tool menu on the bottom of the main screen.

Drag the mouse up/down or left/right to move pan/tilt position of the camera. As you move the mouse away from the center of the screen, the camera movement speed increases. You can also zoom-in/out by using the scroll wheel on the mouse.

Note Full PTZ functions are available using the front panel buttons, a mouse, the IR remote control, or a keyboard controller.

PTZ Popup Menu

Right-click the desired camera to open the PTZ Popup menu while in PTZ mode.

Arrow Buttons – Move Camera

M – Open camera’s on screen display menu (dependant on camera model support, see your camera’s manual for information)

ZOOM – Zoom in/out on PTZ camera. Enabled by default in PTZ mode FOCUS – Adjust focus on PTZ camera.

IRIS – Adjust the iris on PTZ camera.

PRESET – Go to preset position. Select the preset number. The maximum preset number is 255

PRESET TOUR – Start preset tour. PRESET TOUR will sequence though all preset positions. Can only be enabled while in full screen mode.

SOFTWARE TOUR – Create a tour including up to 10 presets stored on the camera and save the tour to the DVR. This works best with cameras that do not have a built-in Tour feature.

________________________________________________________________________________________________________

61
