Steering wheel adjustment | Volvo XC90 instruction

02 Instruments and controls

Steering wheel adjustment

02

G026999

Both the height and the reach of the steering wheel can be adjusted to a comfortable posi- tion for the driver. Pull down the lever on the left of the steering column. Adjust the steering wheel to a suitable position and press the lever back into place to lock the steering wheel in the new position. Check that the steering wheel is locked in the new position.

WARNING

Never adjust the steering wheel while driv- ing.

66

Image 66
