Genie Z-45, Z-25J manual Inspections Inspection for Decals with Symbols

Page 40

Operator's Manual

Fourth Edition · First Printing









Inspections

Inspection for Decals with Symbols

Determine whether the decals on your machine have words or symbols. Use the appropriate inspection to verify that all decals are legible and in place.

Part No.

Decal Description

Quantity







27204

Arrow - Blue

1







27205

Arrow - Yellow

1







27206

Triangle - Blue

2







27207

Triangle - Yellow

2







28158

Label - Unleaded

1







28159

Label - Diesel

1







28160

Label - Liquid Petroleum Gas

1







28174

Label - Power to Platform, 230V

2







28235

Label - Power to Platform, 115V

2







32728

Label - Generator (option)

1







40434

Label - Lanyard Anchorage

3







44981

Label - Air Line to Platform

2







52969

Cosmetic - Genie Boom

1







62926

Cosmetic - Genie Z-45/25J

1







62927

Cosmetic - Genie Z-45/25

1







62947

Cosmetic - IC Power 4 x 2

1







62948

Cosmetic - IC Power 4 x 4

1







72442

Ground Control Panel

1







82238

Platform Control Panel

1







82472

Label - Crushing Hazard

1







82473

Label - Compartment Access

1







Part No.

Decal Description

Quantity









82487

Label - Read the Manual



2









82544

Label - Electrocution Hazard



2









82548

Label - Platform Rotate



2









82587

Label - Tire Pressure,







High Flotation Tires



4









82601

Label - Maximum Load, 227 kg



1









82602

Label - Max Manual Force, 667 N



1









82612

Label - Maximum Load, 200 kg



1









82633

Label - Tire Pressure, RT Tires



4









82646

Label - Drive Enable Patch



1









97815

Label - Lower Mid-rail



1









114023

Label - Wheel Load, Z-45/25



4









114024

Label - Wheel Load, Z-45/25J



4









114114

Label - Transport Diagram



2









114247

Label - Fall Hazard



1









114248

Label - Tip-over Hazard, Tilt Alarm



1









114249

Label - Tip-over Hazard, Tires



4









114251

Label - Explosion Hazard



1







114252

Label - Tip-over Hazard, Limit Switches

3









38

Z-45/25Z-45/25J

Part No.114339
