QoS DSCP Mapping interface

￿

Click

VLAN tag Mapping



to enter VLAN tag priority configuration interface.



























Select the VLAN tag priority level: High, Medium, Normal and Low.



















￿

And then, click

Apply



to apply the configuration



































￿

Or, press

Refresh

to reset the configuration before applying

























QoS VLAN Tag Priority Mapping interface
