Fujitsu M3099EX, M3099GX, M3099GH, M3099EH manual HT DOC . L N e H o t o, Display Explanation

Page 42

Document button

Selects the type of document. When this button is pressed, the lower line is displayed as shown in Screen 8. Each time this button is pressed, “LINE” or “PHOTO” starts blinking in turn and the document selection indication displayed on the upper line changes accordingly.

<Screen 8>
S F A 4
		4 0 0 HT 1		P	. >


DOC . : L . (

	L i n e )		P . ( P h o t o )
			(Blinking)

	Display	Explanation

	P. (Photo)	For light adjustment or when there is a
		dark background color on the docu-
		ment.

	L. (Line)	Select this setting to read line drawing.
	L. (Line)	*1
		*1

*1; Top 3mm part of the read area should be left blank (grounding color ) by specifying a drop-out color.

3-7
