Page 83

show module

Module

Provision

1

dynamic

2

dynamic

3

dynamic

4

dynamic

5

dynamic

6

dynamic

7

dynamic

8

dynamic

9

dynamic

10

dynamic

11

dynamic

12

dynamic

13

dynamic

Router#

Related Commands

Command

Description



show interfaces

Displays the status and statistics for the interfaces in the





chassis.









show environment alarm

Displays the information about the environmental alarm.









show fm summary

Displays a summary of FM Information.









show environment status

Displays the information about the operational FRU status.











Cisco IOS Configuration Fundamentals Command Reference















July 2008





CF-759
