Bits 15-14 contain the Address Method code. This code is used to determine how the remaining 14 bits are to be interpreted by SCSI devices. The following table defines the available Addressing Methods.

Address Method Code





Description





00b

Peripheral device addressing method

01b

Virtual device addressing method

10b

Logical unit addressing method

11b

RESERVED







An overview of the three defined Addressing Methods is given below. The fields are listed as defined in the SAM-2 specification. Details of each Addressing Method are discussed later in this document.

These Address Methods provide alternative user definable paths to SCSI devices. The Peripheral Device Addressing Method (PDAM) is the predominant method and is what is used in the examples that follow. Since by definition, bits 15-14 are 00, it is the only method that can be used by host/environments supporting <16 bits of LUN addressing. If the host/environment can support 16 bits, then any of the 3 addressing methods can apply.

Peripheral Device Addressing Method

Bit Number

15

14

13

12

11

10



9

8

7

6

5

4

3

2

1

0

0

0





Bus

Identifier











Target

/ LUN







By definition, PDAM address 0 (bus = target = LUN = 0) selects the FibreBridge.

The Target field identifies the SCSI ID of the addressed SCSI device. The LUN field will select the logical unit in the addressed target. Since the SCSI Architectural Model – 2 (SAM-2) does not specify exactly which bits are assigned to the Target and which bits to the LUN, the FibreBridge makes this user definable. The default assignments are listed below.

Bit Number

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

0

0



N/A



Bus Identifier



Target





LUN



The location and width of the Bus, Target and LUN fields are field programmable and are stored in the FibreBridge non-volatile RAM. This allows custom address translations to be created to meet special requirements for the customer, operating system, host bus adapter or peripheral device. Another NVRAM
