8. Configuration

8. 7. Configuring monitored parameters

It is possible to select up to 4 parameters to display their values in the [1.2 - MONITORING] menu on the graphic display terminal.

The selection is made via the [6 - MONITORING CONFIG.] menu, [6.3 - COM. MAP CONFIG.] submenu.

Each parameter in the range [Address 1 select.] … [Address 4 select.] is used to select the parameter logic address. Select an address of zero to disable the function.

In the example given here, the monitored words are:

•Parameter 1 = Motor current (LCR): logic address 3204; signed decimal format.

•Parameter 2 = Motor torque (OTR): logic address 3205; signed decimal format.

•Parameter 3 = Last fault occurred (LFT): logic address 7121; hexadecimal format.

•Disabled parameter: address 0; default format: hexadecimal format.

One of the three display formats below can be assigned to each monitored word:

	RDY		NET		+0.00Hz	0A
		6.3 COM. MAP CONFIG.
Word 1 add. select.				:		3204
Format word 1				:		Signed
Word 2 add. select.				:		3205
Format word 2				:		Signed
Word 3 add. select.				:		7121
	Code					Quick
Format word 3				:			Hex
Word 4 add. select.				:		0
Format word 4				:			Hex

Format	Range	Terminal display
Hexadecimal	0000 … FFFF	[Hex]
Signed decimal	-32,767 … 32,767	[Signed]
Unsigned decimal	0 … 65,535	[Unsigned]
