Options Setting Menu

Setting the allocation of the audio connectors

Setting the AUDIO 1, 2, and 3 connectors to the desired picture input.

Example: Setting “AUDIO 1” to “VIDEO 2”

Press the MENU/ENTER button on the remote control to

display the MAIN MENU on the screen, then...

1.Use the ▲ and ▼ buttons to select “OPTIONS”, then press the MENU/ENTER button.

The “OPTIONS” screen appears.

2.Use the ▲ and ▼ buttons to select “AUDIO 1”.

O P T I O N S

AUDIO INPUT















: VIDEO1



AUDIO1







AUDIO2



: HD/DVD1



AUDIO3



: RGB1

BNC SELECT



: RGB

RGB SELECT



: AUTO

HD SELECT



: 1080B

PICTURE SIZE

: ON



SEL.

ADJ.





RETURN



EXIT

3.To set the AUDIO1 to “VIDEO2”...

Use the ￿ and ￿ buttons to select “VIDEO2”.

The mode switches as follows each time the ￿ or ￿ button is pressed:

￿VIDEO1￿VIDEO2 ￿VIDEO3 ￿HD/DVD ￿RGB/PC1￿RGB/PC2 ￿M-LINK*￿

*M-LINK is available only after proprietary tuner/ controller has been connected.

O P T I O N S

AUDIO INPUT















: VIDEO2



AUDIO1







AUDIO2



: HD/DVD1



AUDIO3



: RGB1

BNC SELECT



: RGB

RGB SELECT



: AUTO

HD SELECT



: 1080B

PICTURE SIZE

: ON



SEL.

ADJ.





RETURN



EXIT

4.Once the setting is completed...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once more.

Information

￿AUDIO INPUT

A single audio input cannot be selected as the audio channel for more than one input terminal.

￿Restoring the factory default settings

To restore the original factory settings, go back to the MAIN MENU. Select “FUNCTION,”and then select “RESET”. Note that this also restores other settings to the factory defaults.

Setting the BNC connectors

Select whether to set the input of the 5 BNC connectors to RGB or component video.

Example: Set the BNC SELECT mode to “COMP.”

Press the MENU/ENTER button on the remote control to

display the MAIN MENU on the screen, then...

1.Use the ▲ and ▼ buttons to select “OPTIONS”, then press the MENU/ENTER button.

The “OPTIONS” screen appears.

2.Use the ▲ and ▼ buttons to select “BNC SELECT”.

O P T I O N S

AUDIO INPUT









AUDIO1



: VIDEO1

AUDIO2



: HD/DVD1

AUDIO3



: RGB1





: RGB

BNC SELECT



RGB SELECT



: AUTO

HD SELECT



: 1080B

PICTURE SIZE

: ON

SEL.

ADJ.





RETURN



EXIT

3.To set the BNC SELECT mode to “COMP.”...

Use the ￿ and ￿buttons to select “COMP.”.

The mode switches as follows each time the ￿ or ￿ button is pressed:

RGB COMP.

O P T I O N S

AUDIO INPUT









AUDIO1



: VIDEO1

AUDIO2



: HD/DVD1

AUDIO3



: RGB1





: COMP.

BNC SELECT



RGB SELECT



: AUTO

HD SELECT



: 1080B

PICTURE SIZE

: ON

SEL.

ADJ.





RETURN



EXIT

4.Once the setting is completed...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once more.

Information

￿BNC SELECT

RGB

Use the BNC terminals for a RGB or



RGBHV input.

COMP

Use the BNC terminals for component



input.

￿Restoring the factory default settings

To restore the original factory settings, go back to the MAIN MENU. Select “FUNCTION,”and then select “RESET”. Note that this also restores other settings to the factory defaults.

36
