5.3Connection of Power Cords

WARNING

Do not concentrate power cords only to some AC outlets. If so, fire may occur.

Do not connect the plug of a power cord to an AC outlet with a wet hand. If so, you may be electrically shocked.

Do not put a heavy substance on a power cord. If so, the coating of the power cord may be broken, fire may occur, and/or you may be electrically shocked.

Be sure to use the power cords provided with the additional disk enclosure or NEC-specified power cord.

The additional disk enclosure has the redundant power configuration to prevent the entire unit from shutting down due to a single failure. Therefore, connect two power cords to both power supplies of disk enclosure when operating the additional disk enclosure.

Connect the power cords in the following procedure.

(1)Check of power supply

Check that the power switch of the additional disk enclosure is set to OFF.

OFF

ON

- 25 -
