ILO DTV2784 Memorizing channels, TV/CABLE selection, Press or to select TV/CABLE, Cable Chart

Page 16

Memorizing channels

This TV is equipped with a channel memory feature which allows channels to skip up or down to the next channel set into memory, skipping over unwanted channels. Before selecting channels, they must be pro- grammed into the TV’s memory. This TV can receive up to 250 VHF/UHF channels and 500 cable TV channels. To use this TV with an antenna, set the TV/CABLE menu option to the TV mode. When shipped from the factory, this menu option is in the CABLE mode.

TV/CABLE selection

1 Press MENU. The menu screen will appear.

2 Press or to select (SETUP) menu.

S E T U P

L A N G U A G EE N G L I S H

CLOCK SET



TV/CABLE

CABLE

AUTO CH MEMORY



ADD/DELETE



:SELECT

:ADJUST

- /

3 Press or to select “ TV/CABLE”.

SETUP

LANGUAGEENGLISH

CLOCK SET







TV/CABLE

TV/

CABLE



AUTO CH MEMORY







ADD/DELETE







:SELECT

:ADJUST


SIZE

4 Press

or to select “TV”

























or “CABLE”.























SETUP

















LANGUAGE

ENGLISH





TV

- VHF/UHF channels





CLOCK SET









CABLE - CABLE TV channels





TV/CABLE

TV

/CABLE









ADD/DELETE

















AUTO CH MEMORY

















:SELECT

:ADJUST





















5 Press EXIT to return to the normal screen.

CABLE CHART

The chart below is typical of many cable system channel allocations.

16

Image 16
