Life Fitness Pro Series Abdominal ST05 Specifications, Low Back Extension ST20 Specifications

Page 57

3. Pro Series Machines

Abdominal (ST05) Specifications

Machine Weight:	400 lbs.	181 kg.
Weight Stack:	140 lbs.	70 kg.
Size:	in.= 46 x 37 x 65	cm= 117 x 94 x 165

∙ Dual angled chest pads with a rounded configuration and hand grips provide comfort and upper torso stability.

∙ Starting range limiter provides ease of entry and exit, as well as to accommodate indi viduals with varying torso flexibility.

∙ Diamond plate foot platform adjusts for varying leg length. ∙ Seat height adjusts for torso length.

Low Back Extension (ST20) Specifications

Machine Weight:		580 lbs.	263 kg.
Weight Stack:		300 lbs.	140 kg.
Size:		in.= 40 x 48 x 65	cm= 102 x 122 x 165
∙	Shock dampening system	at extension limit.
∙	Seat belt for better stability.
∙	Adjustable footplate with holddown.
∙	Adjustable back roller pad.

∙ Range of motion limiter accommodates individual flexibility (Model ST25 only).

Cable Crossover (SM20) Specifications

Machine Weight:	841 lbs.	382 kg.
Weight Stack:	190 lbs. x 2	95 kg. x 2
Size:	in.= 31 x 159 x 95	cm= 79 x 404 x 241

∙ Stabilizing handles located above each weight stack.

∙ Swivel pulleys allow for smooth, unobstructed movement. ∙ Textured pull up bar.

∙ Also available with adjustable pulleys (Model SM21 only).

3-48
