SoundCraft 1601E manual Multi Mode, Program Edit and Recall

Additional speed settings for FILTER/FLANGER/PANNER

For example:

FILTER: In single mode, press & hold the FILTER effect button and then rotate the FX SPEED rotary switch to one of its 5 positions to access 1 bar, 2 bar, 4 bar, 8 bar & 16 bar settings.

Default settings ‘4 bars’ for FILTER and FLANGER, 2 bars for PANNER.

MULTI MODE

Multi mode consists of 25 factory preset programs where combinations of the five effects have been carefully setup to offer maximum multi-effects power. The ability to modify the presets in real-time gives added flexibility and allows the user to create customised variations.

The [BANK] rotary switch is used to recall the factory presets from B to F.

See the PRE-SET VOICE LIST for specific preset program parameters.

NOTE: Edited presets are memorised between multi preset selections whilst power remains ON.

PROGRAM EDIT AND RECALL.

Any alterations to the ISOLATOR and X/Y edit parameters will be memorised. When changing between programs the user can set up a program to their own requirement, change to another program(s) and then return to a previous program and have their special set-up recalled.

To reset the factory settings at any time:

Press & hold the current program button and then press TAP/CLEAR to instantly re-load the default set-up.

39
