A&D SW-60KL, SW-6KS, SW-30KM, SW-150KM, SW-15KM, SW-15KS, SW-150KL manual Model SW-60KM

	MODEL	SW-60KM	SW-150KM	SW-60KL	SW-150Kl
	Weighing capacity	60	150	60	150
kg	Minimum display	0.02	0.05	0.02	0.05
		0.01 *	0.02 *	0.01 *	0.02 *
		0.005	0.01	0.001	0.002
	Weighing capacity	130	330	130	330
lb	Minimum display	0.05	0.1	0.05	0.1
		0.02*	0.05*	0.02*	0.05*
		0.01	0.02	0.01	0.02
	Weighing capacity	2100	5200	2100	5200
oz	Minimum display	1	2	1	2
		0.5*	1*	0.5*	1*
		0.2	0.5	0.2	0.5
Ib-oz	Weighing capacity	130	33	130	33
	Minimum display	1	1	1	1
Number of samples		5 (can be changed to 10, 20, 50 or 100) pieces
Maximum count		120,000 pcs	150,000 pcs	120,000 pcs	150,000 pcs
Minimum unit weight		0.0005 kg	0.001 kg	0.0005 kg	0.001 kg
Repeatability		0.01 kg	0.02 kg	0.01 kg	0.02 kg
(Std. deviation)
Linearity		±0.02 kg	±0. 05 kg	±0.02 kg	±0. 05 kg
Sensitivity drift		±20	ppm / °C (5°C to	35°C / 41°F to	95°F)
Display		Weight display: 7 segment LED display (character height 14.6 mm)
		Comparison results: red / yellow / green / yellow / red LED
Display update			10 times per second
Operating conditions			-10°C to 40°C / 14°F to 104°F
		AC main (100V to 240V)
Power supply		or
		optional SLA battery (continuous operation of 90 hours
			depending on how the scale is used)
Weighing pan size		300 x 380 mm / 11.8 x 15.0 in.		390 x 530 mm / 15.4 x 20.9 in.
Dimensions		300 (W) x 601 (D) x 722.5 (H) mm		390 (W) x 751 (D) x 722.5 (H) mm
(Models with a display pole)		11.8 (W) x 23.7 (D) x 28.4 (H) in.		15.4 (W) x 29.6 (D) x 28.4 (H) in.
Mass (approximately)		13.0 kg / 28.7 Ib		16.2 kg / 35.7 Ib
(Models with a display pole)
				60 kg
Calibration weight		60 kg	150 kg		150 kg
(factory setting)		120 lb	300 lb	120 lb	300 lb

* Factory setting

Options

OP-02 SAL Sealed Lead Acid battery (YUASA NP4-6 recommended) OP-03 RS-232C / Relay output

OP-04 RS-422 / 485

Note: The options, OP-03 and OP-04, can not be used at the same time.

40
