Panasonic SL-PR300 Disc Dubbing, Select a disc and start playback, When recording completes

Page 28

Recording onto CD-R/RW Discs

1 Select a disc and start playback.

Example: When planning to record a track on DISC1

1

2 Insert a recordable CD-R or CD-RW disc in the CDR disc tray.

• The disc is read.

3 While the disc is playing back the track you want to record or if that track is being paused, press CD REC (main unit/remote control).

Main Unit



Remote Control







CD REC

CD REC

“1TR DUBBING” is shown in the information display.

•When a blank disc is in the CDR tray, “UPDATE OPC” is shown following “1TR DUBBING”.

When “ADD FINALIZE?” is shown in the information window:

•No response (no input) assumes that finalization is to be per- formed, or you can press the SET button (main unit/remote con- trol) to confirm that finalization is to be done. Press the CANCEL button (main unit/remote control) to keep the disc

unfinalized.

Note

•This message will be shown if the menu FINALIZE function setting is “ON”. The default setting is “OFF”.

The CD restarts playback from the beginning of the track and the CDR starts recording simultaneously.

•When a track is recorded, its digital signals are recorded in their original form. A new track mark is automatically placed at the beginning of the track being recorded.

When recording completes

“STOP DUBBING” flashes and recording automatically stops.

When recorded without canceling “ADD FINALIZE?“

“FINALIZE” is shown in the information window after recording is stopped and finalization is automatically performed.

To stop recording at any time

Press the CD or CDR Control STOP s button on the main unit or the s (stop) button on the remote control to end recording. The recording mode is released after “STOP DUBBING” is shown in the information display.

Notes

•There is no need to adjust the recording level when recording a digital signal.

•If the source CD being recorded from the 3-CD changer is itself a first-generation digital copy, digital recording cannot be per- formed. When this occurs, the recording type will switch from digital to analog automatically.

•Upon completion of recording, “STOP DUBBING” is shown in the information display. Always wait for the “STOP DUBBING” message to be cleared before proceeding with the next operation.

1Disc Dubbing

•You can make a complete copy of a CD that you want to record onto a CD-R/CD-RW disc. When recording a CD with song numbers but no silence between songs such as a live CD, for example, you can use the 1 DISC DUBBING feature to make a recording without any silence.

1

2 3











MULTI JOG



COMPACT DISC RECORDER SL-PR300





–

REC LEVEL

POWER

OPEN /

DISC



+

CLOSE

SELECTOR

OPEN /



DISC 3

3

CLOSE







DISC 2

2









DISC 1

DIGITAL

CD

LINE

REC SELECTOR

PHONES

1





MIX BALANCE

MIN

MAX













LINE

CD

PLAY MODE

CD EDIT

CD REC

SYNCHRO

MENU

SET

CANCEL











FINALIZE

REC/









REC MUTE

1







3

4,5

1

DISC SELECTOR





CD1

CD2

CD3





CD REC

CD EDIT

FINALIZE

DISPLAY





1



2

3





4



5

6





7



8

9





0

>10







PLAY

REPEAT

CONTROL





MODE

CD

CD-R/RW





•REC



FADE

SYNCHRO





REC MUTE









1

4,5

PITCH+

MENU

3



SELECTOR





REC





SET



PITCH–

3

PITCH 0

CANCEL

COMPACT DISC RECORDER

RAK-PR300

1 Select and stop the CD to be recorded.

Example: To record the CD loaded in tray DISC1.

• Only the selected CD is recorded.

1

2 Load a recordable CD-R or CD-RW disc into the CDR and close the tray.

• The disc is read.

3 Press the MENU button (main unit/remote control), and then turn the MULTI JOG control on the main unit or press the P or p button on the remote control until “1 DISC DUBBING” is shown in the information display.

4 Press the SET button.

“DUBING READY?” is shown in the information display.

• Only the selected CD is recorded.

5 Press the SET button.

RQT6087

Page 27 Page 29
Image 28
Page 27 Page 29
Contents Compact Disc Recorder Table of Contents User memo Listening CautionLaser product label has not been attached to this product Features Storage precautions Handling precautionsConcerning CDs Do not place or store CDs in the following placesConnections Analog ConnectionsConnections Digital ConnectionsDigital Optical and Coaxial Cable Connections Optical Cable Input/Output TerminalsComponents Main UnitHeadphones Jack Phones Level Volume ControlRemote Control Sensor ComponentsDisplay Window Using the Remote Control Remote ControlUsing the Remote Control Using the Remote ControlInserting the Batteries Power STANDBY/ON Operations Turning the Power On and Standby ModeTo turn power to the unit on To put the unit in standby mode during operationPlaying CDs using the CD Control Play pbutton Listening to CDsCD Changer Continuous Playback Press the Disc Selector 1 buttonListening to CDs CDR Playback OperationsUsing the Remote Control to Control Playback To stop CDR playback temporarilyRemoving a CD from the CDR Press the CD or CDR button to select the deckDirect Playback of a Specific Track Forward and Reverse SearchPress the number buttons of the track you want to play To select a two-digit track numberSetting the repeat play mode Using repeat mode during program or random play modesSkipping Tracks Repeat PlaybackTo release the random playback mode To adjust the pitch of a CD during playbackRandom Playback CD Playback Pitch ControlProgramming Playback Using Main Unit Controls Load CDs into the trays of the 3-CD changerPress the SET button to start program registration Repeat steps 4 and 5 to program up to a maximum of 32 stepsProgramming Playback Using the Remote Control Press the Play Mode buttonPress the CD Control Play p button to start programmed play Press the SET buttonRepeat steps 5 and 6 to program up to a maximum of 32 steps Press the p button to start program playAdd Finalize Feature To enable the Add Finalize featureRecording onto CD-R/RW Discs Read through this section before recordingRecording onto CD-R/RW Discs Manual RecordingTo increase the recording level from Line Turn the Multi JOG to select High Press the SET buttonPress 1REC/REC Mute to put the CDR in recording pause mode When recording is completeTo record silence in the recording Auto Track function onTo add track marks automatically Synchronized Recording of 3-CD Changer PlaybackAuto Track function off When ADD FINALIZE? is shown in the information window Select and stop the CD to be recordedTo stop the recording at any time Checking a track number during recordingWhen recording completes Disc DubbingSelect a disc and start playback Insert a recordable CD-R or CD-RW disc in the CDR disc trayWhen the first track has been stored in memory Listening Edit RecordingProgram Edit Recording Load CDs in the 3-CD changerLoad a recordable CD-R or CD-RW disc in the CDR tray Recording process startsSelect and enter a track number Select and enter the disc numberRepeat steps 4 and 5 to continue programming tracks Setting the Unit for High-speed Recording Pess the SET buttonPress the Synchro button main unit/remote control Synchronized Recording from External SourcesStart playing of the source unit Synchronized recording to the CDR from an external sourceMixed Input Recording Load a recordable CD-R or CD-RW in the CDR disc trayMIX Balance Line Skipping a Recorded Track on a CD-R or CD-RW Track Skip Special Recording Edit OperationsErasing a Track or Tracks Erase Function CD-RW only Erasing All Tracks Disc Erase Function CD-RW only Special Recording Edit OperationsLoad the CD-RW to be erased in the CDR disc tray Finalizing a Disc Press the Finalize button main unit/remote controlLoad a finalized CD-RW disc into the CDR disc tray Press the SET button again to confirm the operation Resetting the Unit to Factory Default Settings 4 CancelWays to change or adjust the time display Setting the ClockExample Setting the Clock To ascertain the correct timeTimer Operations Timer Play wake-up playTimer Operations Set the power to standby modeWith Unit Power Turned On From Standby ModeLoad a recordable CD-R or CD-RW disc into the CDR CD and CDR Messages Message Significance RemedyCD and CDR Messages Disc FullScms Serial Copy Management System Troubleshooting CommonProduct service SpecificationsProduct information

SL-PR300 specifications

The Panasonic SL-PR300 is a remarkable portable CD player that combines advanced technology with user-friendly features. Released during the height of the CD boom, it showcased Panasonic’s commitment to quality audio and innovative design in portable music solutions.

One of the standout features of the SL-PR300 is its compact and lightweight design, making it easy to carry for on-the-go listening. The player measures just under 1.5 inches thick, allowing it to fit comfortably into bags and backpacks, making it a popular choice for travel enthusiasts.

The SL-PR300 is equipped with a high-quality 1-bit Digital-to-Analog Converter (DAC), which ensures clear and precise sound reproduction. This technology enhances audio quality by reducing distortion and providing a more immersive listening experience. The player supports a range of CD formats, including standard audio CDs and CD-R/RW discs, making it versatile for various music collections.

One of the innovative features integrated into the SL-PR300 is the anti-shock technology, designed to minimize skips and interruptions during playback. This is particularly beneficial for users who enjoy listening while they move, providing a smooth experience even when walking or exercising.

Additionally, the SL-PR300 offers a rechargeable battery option, providing convenience and sustainability for music lovers. Users can easily recharge the player, reducing the need for disposable batteries and allowing extended listening sessions without interruption. The long battery life also ensures that users can enjoy their music without frequent recharging, perfect for long journeys or outdoor activities.

For ease of use, the SL-PR300 features an intuitive interface with simple controls, allowing users to navigate their playlists effortlessly. The large, easy-to-read LCD screen provides essential information such as track number and playback time, enhancing the overall user experience.

In terms of connectivity, the player includes a headphone jack, providing a direct and personal listening experience. The SL-PR300’s durable construction ensures it can withstand the rigors of daily use, making it a dependable choice for music enthusiasts looking for a reliable portable CD player.

In summary, the Panasonic SL-PR300 stands out in the portable audio market with its combination of advanced technology, user-friendly design, and portability. With features such as anti-shock technology, rechargeable battery options, and high-quality audio output, it remains a noteworthy choice for anyone looking to enjoy CDs on the go.
