Spray Techniques

Spray Techniques

Nozzle Selection

IMPORTANT

Keep pump and hose clean when switching between simulated acoustic, knockdown and orange peel applications. A dirty pump can release particles of texture into the finish.

Nozzle Selection

Application

Nozzle Orifice2

Nozzle No.

Air Volume1









Fog

1/8 in.

3

high











3/16 in. (fine)

4











Simulated Acoustic

1/4 in. (fine to med)

6

medium to high







5/16 in. (coarse)

8











Orange Peel

1/8 to 3/16 in.

3-4

medium to high









Splatter Coat

1/4 to 5/16 in.

6-8

low - medium









Knock-down

5/16 in.

8

low









1Control air volume with gun air flow valve (31).

2For more material volume, try a larger-orifice tip.

16

309915D
