3Com 56K manual Complete list of S-Registers, Register Default Function

A complete list of S-Registers A-5

A complete list of S-Registers

.

Register Default Function

S0	0	Sets the number of rings on which to answer in Auto
		Answer mode. S0=0 disables Auto Answer. S0=1 enables
		Auto Answer and the Business Modem answers on the first
		ring.
S1	0	Counts and stores the number of rings from an incoming
		call.
S2	43	Stores the ASCII decimal code for the escape code
		character. Default character is “+”. A value of 128-255
		disables the escape code.
S3	13	Stores the ASCII decimal code for the Carriage Return
		character. Valid range is 0-127.
S4	10	Stores the ASCII decimal code for the Line Feed character.
		Valid range is 0-127.
S5	8	Stores the ASCII decimal code for the Backspace character.
		A value of 128-255 disables the Backspace key's delete
		function.
S6	0	Set the number of seconds the Business Modem waits for a
		dial tone.
S7	60	Sets the number of seconds the Business Modem waits for
		a carrier. May be set for much longer duration if, for
		example, the Business Modem is originating an
		international connection.
S8	2	Sets the duration, in seconds, for the pause (,) option in the
		Dial command and the pause between command
		reexecutions (> and A> commands).
S9	6	Sets the required duration, in tenths of a second, of the
		remote device's carrier signal before recognition by the
		Business Modem.
S10	14	Sets the duration, in tenths of a second, that the Business
		Modem waits after loss of carrier before hanging up. This
		guard time allows the Business Modem to distinguish
		between a line hit, or other disturbance that momentarily
		breaks the connection, from a true disconnect (hanging up)
		by the remote device
S11	70	Sets the duration and spacing, in milliseconds, of dialed
		tones.
S12	50	Sets the duration, in fiftieths of a second, of the guard time
		for the escape code (+++) sequence.
