TECHNICAL INFORMATION

Technical	Your modem uses multiple standard data communications protocols and
Specifications	is also compatible with many nonstandard schemes. The following
	schemes are supported:

Modulation

This modulation Supports

V.90	ITU 56K standard, server capabilities. V.90 analog
	clients can call into your Business Modem to get
	56K connections
x2	Up to 56 Kbps downstream and V.34 speeds upstream
ITU-T V.34	33.6/31.2/28.8/26.4/24/21.6/19.2/16.8/14.4/12 kbps;
	9600/7200/4800 bps asynchronous Trellis Coded
	Modulation (TCM)
V.FC	28.8/26.4/24/21.6/19.2/16.8/14.4 kbps asynchronous
	TCM
V.32 terbo	21.6/19.2/16.8/14.4/12 kbps; 9600/7200 bps
	asynchronous TCM; 4800 bps asynchronous Quadrature
	Amplitude Modulation (QAM)
HST	16.8/14.4/12 kbps; 9600/7200 bps asynchronous,
	asymmetrical, 450 bps back channel with automatic
	handshake adjustment to 300 bps TCM and QAM; 4800
	bps asynchronous, asymmetrical, 450 bps back channel
	with automatic handshake adjustment to 300 bps QAM.
ITU-T V.32 bis	14.4/12 kbps; 9600/7200 bps asynchronous TCM; 4800
	bps asynchronous QAM
ITU-T V.32	9600 bps asynchronous, TCM; 4800 bps asynchronous,
	QAM
ITU-T V.22 bis	2400 bps asynchronous, QAM
Bell 212A	1200 bps (also V.22) asynchronous, Differential Phase
	Shift Keying (DPSK)
