PC Processors (Pentium 4)

Created by IBM PC Institute Personal Systems Reference (PSREF)

Intel→ Pentium→ 4 for high performance desktop systems

	1.3GHz, 1.4GHz, 1.5GHz, 1.6GHz, 1.7GHz, 1.8GHz, 1.9GHz, 2.0GHz
Code name	Willamette
Micro-architecture	IA-32 / NetBurst™ (CISC/RISC/micro-ops) / 20 stage pipeline (Hyper-pipelined technology)
MMX™ / Streaming SIMD	MMX™ (57 new instructions) / Streaming SIMD Extensions (70 new instructions)
SSE2	Streaming SIMD Extensions 2 (144 new instructions)
L1 cache - bus	256-bit data path / full speed
L1 data cache	8KB data cache / 4-way set associative / write-through / 64 byte cache line / integrated
L1 instruction cache	Size not published / holds 12,000 micro-ops / 8-way set associative / integrated /
	called Execution Trace Cache; caches decoded x86 instructions (micro-ops)
L2 cache - size	256KB / full speed (Advanced Transfer Cache)
L2 cache - data path	256-bit data path (32 bytes) / transfers on each bus clock / 128 byte cache line size (usually divided into two 64 byte
	sectors) / 8-way set associative / integrated / unified (internal die; on die) / ECC

Front Side Bus Memory addressability Front Side Bus - width

400MHz (transfers data four times per clock) / address bus transfers at two times per clock / 64 byte cache line size 64GB memory addressability / 36-bit addressing / address bus is double clocked at 200MHz

64-bit data path

Execution units	2 integer units; 1 floating point units; 1 load unit; 1 store unit
	Two integer units (or Arithmetic Logic Units) run at two times core frequency (Rapid Execution Engine)
Out-of-order instructions	Yes
Branch prediction	Dynamic (based on history) / 4KB Branch Target Buffer
Speculative execution	Yes (Advanced Dynamic Execution)
Math coprocessor	Pipelined floating point unit / handles 128-bit floating point registers
Compatibility	Compatible with IA-32 software
Cache line size	128 bytes (32 bytes x 4 chunks); burst mode bus of addr-data-data-data
Multiple processors	No SMP support
Technology (micron)	0.18u
Transistors	~42 million with die size of 217 square millimeters
Package and connector	1. Pin Grid Array (PGA) requires 423-pin Zero Insertion Force (ZIF) socket named Intel Socket 423 (PGA423);
	used with RDRAM-based 850 chipset
	2. Flip-Chip Pin Grid Array-2 (FC-PGA2) requires 478-pin surface mount Zero Insertion Force (ZIF) socket
	named mPGA478B socket; used with SDRAM-based chipset (such as 845 chipset)
Frequency (MHz)	1.3GHz: 423-pin available January 2001
and available date	1.4GHz: 423-pin available November 2000
	1.5GHz: 423-pin available November 2000, 478-pin available August 2001
	1.6GHz: 423-pin available November 2000, 478-pin available August 2001
	1.7GHz: 423-pin available November 2000, 478-pin available August 2001
	1.8GHz: 423-pin available November 2000, 478-pin available August 2001
	1.9GHz: 423-pin available November 2000, 478-pin available August 2001
	2.0GHz: 423-pin available November 2000, 478-pin available August 2001
Chipset support	Intel 850 with dual channel RDRAM memory
	Intel 845 with SDRAM memory
All trademarks are the property of their respective owners		(14INTEL) Compiled by Roger Dodson, IBM. August 2001
