Technicalspecifications
XFAX- User’s Guide 4.3a 61
US Robotics Courier(with Class 2.0)
US Robotics Sportster(with Class 2.0)
ZyXEL U-1496E
ZyXEL Omni 288S
ZyXEL U90F
Problemscan arise - particularly sensitive is the reception of faxes - if theserial
ports whichare used are not of good quality. The ports should be equipped with
UART16550 or similar circuits with buffering. Intelligent cardssuch as Digi-
Board are equippedwith such circuits.
17.6 Typefaces in XFAX
The followingtypefaces are built into XFAX with their respective escape
sequences:
Courier10 cpi <ESC>(s0p0b0s0t10H
Line Printer 16.6 cpi <ESC>(s0p0b0s3t16.6H
Helvetica8 pt <ESC>(s1p0b0s4t8V
Helvetica10 pt <ESC>(s1p0b0s4t10V
Helvetica12 pt <ESC>(s1p0b0s4t12V
Helvetica 10 pt, italics <ESC>(s1p0b1s4t10V
Helvetica 12 pt, italics <ESC>(s1p0b1s4t12V
Helvetica10 pt, bold <ESC>(s1p3b0s4t10V
Helvetica14 pt, bold <ESC>(s1p3b0s4t12V
Helvetica14 pt, bold <ESC>(s1p3b0s4t14V
TimesRoman 10 pt, italics <ESC>(s1p3b1s4t10V
TimesRoman 12 pt, italics <ESC>(s1p3b1s4t12V
TimesRoman 10 pt, bold <ESC>(s1p3b0s5t10V
TimesRoman 12 pt, bold <ESC>(s1p3b0s5t12V
TimesRoman 14 pt, bold <ESC>(s1p3b0s5t14V
TimesRoman 8 pt <ESC>(s1p0b0s5t8V
TimesRoman 10 pt <ESC>(s1p0b0s5t10V
TimesRoman 12 pt <ESC>(s1p0b0s5t12V
