Samsung S500 Games , Media box

Fun Box

118

GPRS first: your phone will search for the GPRS

network first. If this service is not available, you

can set the GSM service temporarily.

GPRS only: it only works in GPRS network.

GSM only: it only works in GSM network.

Current Proxy

(Menu 7.1.6)

This menu option allows you to activate one of the

proxies you set up to use the WAP connection.

Media box

(Menu 7.2)

You can view the images and melodies available in

your phone.

The following options are available:

Image: allows you to view the images received

from other sources, such as the Internet or other

phones. Press the Options soft key to rename or

delete the image.

Melody: allows you to listen to the melodies

received from other sources, such as the Internet or

other phones. Press the Options soft key to

rename or delete the melody.

Note:

You can not delete the melodies which are used

as current ringtones or other melody settings.

Delete all: deletes all of the images and melodies

in the media box. Place or remove a check mark

ahead of the item you want to delete by pressing

the Select soft key, and then press the Ok soft key.

Fun Box

119

Games

(Menu 7.3)

Using this menu option, you can also enjoy playing

three games.

Scroll to the required game by pressing the Up or

Down key and press the Select soft key.

To select an option, press the corresponding

number key. The following options are available:

New game: allows you to start a new game.

High score: shows you the High Score table. Not

all games have this option.

Key info.: shows you which keys do what within

the game.

Continue: allows you to continue the game you

played previously. The menu is only available when

a game has already been played.

While you are playing a game:

At the end of the game, if your score is ranked fifth

or higher, you may enter a name of up to 10

characters.

To Press the

adjust the game

volume

volume keys.

pause/resume the

game

C key.

exit the game key or right soft key.
