REPAIR PARTS

HANDLES

SNOW THROWER - MODEL NO. 927SB (96193004400), PRODUCT NO. 961 93 00-44

7

1

4



3



5

2











KEY

PART





4

NO.

NO.

DESCRIPTION

6

5

1

532 42 13-81 CONSOLE PANEL GRAY





2

532 42 14-48 HEADLIGHT BEZEL GRAY





3

532 18 09-27 FLOOD HEADLIGHT





4

532 18 44-71 SHOULDER SCREW 10−24 X .625



01.10.012-A

5

532 17 52-62 SCREW 10−24 X 1.25



6

532 17 87-70 WIRE HARNESS









7

532 18 37-84

BULB

1

KEY

PART



NO.

NO.

DESCRIPTION

1

532 42 10-59

LOWER TUBE

2

532 42 21-17 PIVOT SUPPORT

3

532 15 00-78 BOLT 5/16−18 X .750

4

817 00 06-16

SCREW 3/8−16 X 1.00

4

4

2

3

4

01.05.003-B

4

NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm

IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty. 26
