F u l l - Size CPU Card	S B C - 7 8 0

2.4 List of Jumpers

The board has a number of jumpers that allow you to configure your system to suit your application.

The table below shows the function of each of the jumpers of the board:

Jumpers

Label	Function
JP2	LCD Voltage Selection

JP3	TTL-LCD Clock Selection

JP6	COM2 RS-232/422/485 Selection

JP7	COM2 RS-232/422/485 Selection

JP8	Clear CMOS

JP10	PCI-104 I/O Voltage Selection

JP11	COM2 Ring/+5V/+12V Selection

Chapter 2 Quick Installation Guide

2 - 7

Image 20
