TANDBERG D50104-15 user manual PC Presenter, PC SoftPresenter

Page 52

‘PC: VNC’ MUST BE SET IN ‘VIDEO SETTINGS’.

General Use

Health Care System III

PC Presenter

Plugging a PC into the system is made extremely simple through the PC Presenter, avoiding the need for any additional hardware such as a projector, PC/Video converter or extra cables.

•Start your PC.

•Press PC on your remote control.

•Press SELFVIEW until the indicator ‘Selfview‘ is displayed on your main monitor (single monitor system) or until you see the PC image on the second monitor.

If no PC image is displayed on your monitor, make sure that your PC transmits the image to the VGA Output, and that the PC transmits a supported VGA-format (see tip below). Consult your PC-operating manual to see how to transmit a VGA image from your PC (typically: Fn+F5).

VGA-FORMATS SUPPORTED (VESA COMPLIANT)

·640X480	60,72,75,85 HZ
·800X600	56,60,72,75,85 HZ
·1024X768	60,70,75 HZ

PC SoftPresenter *

PC SoftPresenter is used to display PC images on your system. The system and your PC must be connected to a LAN. In addition, VNC (Virtual Network Computing) server software must be installed on the PC.

NOTE

To show the PC image:

•Start the VNC software on your PC.

•Press PC on your remote control. Use UP/DOWN to activate PAGE UP/PAGE DOWN on the PC. For setup information and details, see ‘VNC Settings’ in ‘Advanced use’.

* - Optional feature.

52
