Dell NU229, ATG E6400, PP27L Secure Digital SD Memory-Card Reader, Ports and Connectors

Secure Digital (SD) Memory-Card Reader

Cards supported	SD, SDIO, SD HC, Mini SD (with adapter)
	MMC, MMC+, Mini MMC (with adapter)
Memory
Memory module connector	two DIMM sockets
Memory module capacities	512 MB (one DIMM)
	1 GB (one DIMM or two DIMMs)
	2 GB (one DIMM or two DIMMs)
	3 GB (two DIMMs)
	4 GB (one DIMM or two DIMMs)
	8 GB (two DIMMs, requires 64-bit
	Windows XP or Windows Vista operating
	system)
Memory type	DDR2 800 MHz (if supported by chipset
	and/or processor combinations); non-ECC
	memory only
Minimum memory	512 GB
Maximum memory	8 GB (requires 64-bit Windows XP or
	Windows Vista operating system)

NOTE: In order to take advantage of the dual-channel bandwidth capability, both memory sockets must be populated and must match in size.

NOTE: The available memory displayed does not reflect the complete maximum memory installed because some memory is reserved for system files.

NOTE: To enable Intel® Active Management Technology (iAMT), you must have a DIMM in the memory connector labeled A. For more information about the memory connector see your computer’s Service Manual at support.dell.com. For more information about iAMT, refer to the Dell™ Systems Management Administrator's Guide at support.dell.com.

Ports and Connectors

Audio	microphone connector and stereo
	headphone/speakers connector
IEEE 1394a	4-pin connector

22

Specifications
