SETTING THE RECORDING METHOD

Note:

•Illumination

The shutter speed for this camera is set automatically in accordance with the brightness of the object being recorded. If the object being recorded is moving and the resulting images are out of focus, increase the amount of illumination.

•Image quality

The images on the monitor screen comply with a digital image format (VGA equivalent: 640 x 480 dots), so the resolution will appear less sharp than images which are displayed on a computer screen.

Image 39
